| Minimum Order Quantity: | 20 Pieces |
|---|---|
| Price: | $1,770.00/Pieces 20-49 Pieces |
| Material: | Metal | Warranty: | 1 Year |
|---|---|---|---|
| After-sale Service: | Free Spare Parts | Port: | Shanghai |
| Highlight: | Metal 0.85M Electric Hospital Bed,240kgs Electric Hospital Bed,adjustable bed for patient Single Crank |
||
New Arrival Metal Single Crank Folding Metal Hospital Bed For Medical|
Name
|
Requirements
|
|
Specification
|
2200(±50mm)×950(±50mm)×380-850(±50mm)mm;
|
|
Bed frame
|
It is welded with a 40×80×1.2mm rectangular tube, the surface is flat, and there is no trace of welding seam;
|
|
Bed panel
|
The bed board is made of steel strips with a thickness of ≥1.5mm, and the four frames of the back board are reinforced with sheet metal to enhance the load-bearing capacity. The metal surface is electrostatically sprayed with epoxy powder. In order to achieve the purpose of anti-rust and antibacterial on the surface of the workpiece, the workpiece is required to undergo acid derusting, alkali neutralization, degreasing, water rinsing, phosphating, electrophoresis, drying, spraying and other processes. Standard of use: The bed panel has no sound when the patient goes to bed, turns over and the bed panel is raised and lowered, and is firm and reliable without looseness;
|
|
Bed body
|
Load ≥240kg, cold-rolled steel plate, double-layer stable structure, strong and durable; anti-collision angles are installed on the outside or four corners of the bed;
|
|
Folded
|
Back folding≥0-75°leg folding≥0-40° Back-knee linkage With vertical head supine function: 0-12°±2° Overall lifting: 380~850mm
One-button chair position |
|
Head and foot board
|
Adopt ABS head and foot board, arc-shaped smooth design, beautiful and generous, with hidden locking device, stable and reliable,
easy to disassemble, there is patient information card slot on the outside of the foot board; Backup battery with backup battery |
|
Spare battery
|
With backup battery
|
|
Universal wheel
|
With four double-piece plastic-coated wheels, the bed can rotate flexibly and without noise; diameter: ≥125mm, with locking,
universal and directional central control locking device. Equipped with anti-collision device. |
|
Guardrail
|
Aluminum alloy folding guardrail, hardened and strengthened (high strength, metal lower seat), combined with movable side, easy maintenance, guardrail switch is placed in the direction of the bed, safe, reliable, solid and durable; total length is about 1450mm, when unfolded Height ≥380mm. Retractable and lifted freely, durable, not easy to deform, smooth and beautiful, easy to clean, the guardrail has six levels;
|
|
Infusion stand socket
|
There are two infusion stand sockets (two on the left and two on the right), which are easy to push out for inspection and use.
There is a drainage hook on both sides of the inner side of the bed frame, and a sundries rack is provided at the bottom of the bed; |
|
Material
|
The surface of the bed frame, bed board, screw, crank, bed leg, etc. must be smooth and durable;
|
|
Mattress
|
(1) Specifications: matching with hospital beds, ≧6mm thick;
(2) Material: ① 4 cm sponge, 4 cm brown, high-density brown flakes, processed by high temperature and high pressure, high-density elastic sponge, pest-proof treatment to prevent deformation, breathable, moisture-permeable, mildew-proof, wear-resistant, with The zipper can be detached flexibly; ②Outsourcing high-quality waterproof cloth, liquid does not penetrate the surface, easy to wipe, and breathable;
(3) It can be bent according to the lifting of the back, feet and legs of the bed;
|
|
Motor
|
Imported motor is adopted, which meets international requirements and has a service life of 5 years.
|
|
CPR
|
With manual CPR function
|
