| Place of Origin: | Jiangsu, China |
| Brand Name: | Dinggong |
| Certification: | ISO,CE |
| Model Number: | DG-A03 |
| Minimum Order Quantity: | 20 Pieces |
|---|---|
| Price: | $290-270.00/Pieces 20-49 Pieces |
| Packaging Details: | with a box |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 30 Box/Boxes per Month |
| Material: | Metal | Warranty: | 1 Year |
|---|---|---|---|
| After-sale Service: | Free Spare Parts | Port: | Shanghai |
| Highlight: | 970MM five function icu bed,Nursing five function icu bed,240kg hospital bed fully electric |
||
|
name
|
Requirements
|
|
Specification
|
2200(±50mm)×970(±50mm)×350-800(±50mm)mm;
|
|
Bed frame
|
It is welded with a 40×80×1.2mm rectangular tube, the surface is flat and there is no trace of welding seam;
|
|
|
The bed board is made of steel strips with a thickness of ≥1.0mm, and the four frames of the back board are reinforced with sheet metal to enhance the load-bearing capacity. The metal surface is electrostatically sprayed with epoxy powder. In order to achieve the purpose of anti-rust and antibacterial on the surface of the work piece, the work piece is required to suffer acid derusting,
alkaline neutralization, degreasing, water rinsing, phosphating, electrophoresis, drying, spraying and other processes. Standard of use: The bed panel has no sound when the patient goes to bed, turns over and the bed panel is raised and lowered, and is firm and reliable without looseness;
|
|
bed body
|
Load ≥240kg, cold-rolled steel plate, double-layer stable structure, strong and durable; anti-collision angles are installed on the outside or four corners of the bed;
|
|
Fold
|
Back folding≥0-75°Leg folding≥0-40°Overall lifting 35-80°
|
|
Head and foot board
|
Adopt ABS head and foot board, smooth arc design, beautiful and generous, with hidden locking device, stable and reliable, easy to disassemble, there is a patient information card slot on the outside of the foot board;
|
|
Crank
|
Built-in crank handle, equipped with ABS stacked hand crank. The screw rod is made of 45# steel, which is formed by a special rolling machine. The wire mouth is smooth and easy to operate. The mother wire is made of ductile iron . The screw rod has two directions. Neutral protection device;
|
|
Universal wheel
|
Four custom-made 5-inch double-sided polyurethane bidirectional brake universal wheels that have passed Pony's test, and the bed rotates flexibly and without noise;
|
|
Guardrail
|
ABS four-leaf guardrail, stylish and beautiful design, movable side-placed combination, easy to maintain, guardrail switch is placed under the guardrail, easy to operate, safe, reliable, solid and durable; retractable and liftable, not easy to deform, smooth, beautiful and easy to clean.
|
|
Infusion stand socket
|
There are two infusion stand sockets (two on the left and two on the right), which are easy to push out for inspection and use. There is
a drainage hook on both sides of the inner side of the bed frame, and a sundries rack is provided at the bottom of the bed; |
|
Material
|
The surface of the bed frame, bed board, screw, crank, bed leg, etc. must be smooth and durable;
|
|
Mattress
|
(1) Specifications: matching with hospital beds, ≧6mm thick;
(2) Material: ① 4 cm sponge, 4 cm brown, high-density brown flakes,
Processed by high temporarative and high presenture, high-density elastic sponge, Pest-PROOF TREATMENT to Prevent Deformation, Breathable, Mildew-PR OOF, Wear-Resistant, With the Zipper Can Be Detached Flexibly; ②Outsourcing High-Quality WaterProof C C C the lot , liquid does not penetrate the surface, easy to wipe, and breathable;
(3) It can be bent according to the lifting of the back, feet and legs of the bed;
|
|
the motor
|
Adopt domestic motor
|
